Description:
The AN188 is a miniature size on/off and metering plug to control lighting and appliances. It is possible to turn on/off home devices and check the status directly from a smartphone.
Compact in design, yet certified for safety by makes it suitable for plugging into any power outlet. The metering plug can support wattage, voltage, ampere, and measurement. The unit can also detect overload upon which the unit will switch off relay and keep LED flashing until power is off and re-applied.
Features:
– Wireless two-way communication
– Comply with S2 security solution
– Auto-pairing to the gateway
– Measure kW/h in 2 decimal accuracy
– Remembers last status before power cut
– Overload detection and cut-off
– Both instant power wattage and accumulated power consumption KWh report
– Reports when power usage exceeds preset value
Specifications:
– Function: Mini on/off and metering plug
– Frequency range: 868.42 MHz
– RF protocol: Z-Wave Plus, SDK 6.71
– RF range (open space): >150m
– User interface: 1 x LED/button
– Max load: 3000W resistive load, 1500W incandescent load, 420W fluorescent load, 450W LED load (non-dimmable)
– Plug type: German (AN188-2), French (AN188-6)
– Power input: AC220V – 240V / 50Hz
